UEFI SecureBoot on Debian

This post explains how to enable UEFI SecureBoot on Debian, using your own trust chain. The technical part itself is very light, most of the post is explanations and what and why.

What is SecureBoot ?

UEFI SecureBoot is a mechanism to verify a cryptographic signature of UEFI Images before loading them into the Firmware (the new name for the BIOS¹). This provides a way to control which images are allowed, and also drivers and option ROM used by the Firmware, and to fight bootkits and malwares based on that. For an example of such dangers, see my past presentations on malicious UEFI Option ROMs ([FR] at SSTIC, and [EN] at PacSec).

Roughly, SecureBoot will rely on cryptographic signatures (mainly using SHA-256 and RSA-2048) that are embedded into files using the Authenticode file format. The integrity of the executable is verified by checking the hash, and the authenticity and the trust by checking the signature, based on X.509 certificates, which has to be trusted by the platform.

Overview

At a high level, the Firmware has 4 different set of objects (see figures for details):

Overview

the Platform Key (PK): this is the main key. This keys, usually belonging to the platform owner, controls if the ownership can be changed, or if other keys can be modified.
The Key Exchange Key (KEK): these keys control which certificates can be used to sign images.
The Authorized Signatures Database (DB): this database contains authorized signing certificates, but also some hashes. Any image, either signed with a certificate enrolled in DB, or having a hash stored in DB, will be allowed to boot.
The Forbidden Signature Database (DBX): this database stores forbidden certificates and images hashes. Any Image listed here will never be allowed to run (even if also listed in DB).

PK and KEK keys are Certificate Authorities. There can be several KEKs, but they must be signed by the PK. On a typical system, the PK is owned by the manufacturer, as well as one of the KEKs. Another KEK belongs to Microsoft (so the system can boot Windows by default), and that’s it.

So, why would you want SecureBoot ? Because it’s a good thing in the general intention (it protects you from malwares), but only if the OEM does grant you the ability to add/change/modify the Certificate Authorities. It improves the trust in the boot sequence, and brings you more control over it.

For more details, see the UEFI specifications, and the Linux Foundation Whitepaper about UEFI Secure boot.

Installing the tools

The sbsigntools and efitools packages are required. Unfortunately, they are not yet in the Debian mainstream distribution. I have created some packages and have submitted them, at the moment of the writing of this post they are currently sitting in NEW.

In the meantime, you can use the packages from the openSUSE build system, or build them from the sources. The sbsigntool git tree can be found here, and the efitools git tree is here.

For EfiTools, you can also use the UEFI keytool USB image from James Bottomley’s website called sb-usb.img (md5sum 7971231d133e41dd667a184c255b599f).

Configuring SecureBoot

There are two possibilities for SecureBoot:

you trust the OEM and Microsoft authorities (or, your device does not allow going back to Setup Mode)
you trust only your own CA

The first case is not described here. It means using shim, which is a bootloader signed by a certificate issued by Microsoft, to chain with your own bootloader. This is mostly useful in case of dual-boot, or when you don’t have your own CA. In my case, the goal sto fully control what can boot or not on my device, and check its integrity, so I will only describe the second case.

Prerequisites

Before going further, there are some checks to be done:

SetupMode

Obviously, the Firmware must support UEFI and SecureBoot.
The Firmware must support Setup Mode, or at least clearing the keys. If it does not, there is no point running your own CA, using shim will be enough, since any executable signed by Microsoft or your OEM will be able to boot².
A PKI, and a way to manage (generate and sign) your X.509 certificates.

Note that this is likely to be easier on laptops, because all drivers are embedded in the image. On a desktop, it is probable that external drivers (especially Option ROMs for devices such as graphics card) will need to be signed.

Set a Firmware password

First, you need to lock the settings of the Firmware, and make sure that SecureBoot cannot be disabled. To do this, setting a password (at least admin) to the Firmware is required.

Generate the certificates

Three certificates are required:

the PK
the KEK
the boot certificate

This part is not covered here. If you have your own Certificate Authority, then you should be able to generate your certificates easily.

If you don’t, here’s how to generate a few self-signed X.509 certificates for testing:

umask 0077
# create a PK key
openssl req -new -x509 -newkey rsa:2048 -subj "/CN=my PK name/" -keyout PK.key -out PK.crt -days 3650 -nodes -sha256
# create a KEK key
openssl req -new -x509 -newkey rsa:2048 -subj "/CN=my KEK name/" -keyout KEK.key -out KEK.crt -days 3650 -nodes -sha256
# create a db key
openssl req -new -x509 -newkey rsa:2048 -subj "/CN=my db name/" -keyout db.key -out db.crt -days 3650 -nodes -sha256

Convert them to the correct format, put them on a USB drive

Convert the certificates to the expected format:

$ cert-to-efi-sig-list /tmp/CA/PK.crt /tmp/CA/PK.esl
$ cert-to-efi-sig-list /tmp/CA/KEK.crt /tmp/CA/KEK.esl
$ cert-to-efi-sig-list /tmp/CA/boot0.crt /tmp/CA/db.esl

Establish the trust chain: the PK will be self-signed, the KEK will be signed by the PK, and the boot certificate will be signed by the KEK

$ sign-efi-sig-list -k PK.key -c PK.crt PK /tmp/CA/PK.esl /tmp/PK.auth
$ sign-efi-sig-list -k PK.key -c PK.crt KEK /tmp/CA/KEK.esl /tmp/CA/KEK.auth
$ guid=$(uuidgen)
$ sign-efi-sig-list -k KEK.key -c KEK.crt $guid /tmp/CA/db.esl /tmp/CA/db.auth
$ ./cert-to-efi-sig-list dbx.esl

Copy the keys (the public parts only) to a USB drive, and save the private parts elsewhere (in a safe location).

Now, we’ll use the boot certificate key to sign boot images.

Option 1: create a UEFI Linux kernel

Note that you don’t really need a bootloader: the kernel image can be compiled as a UEFI Image (CONFIG_EFI_STUB). However, in that case, there is no support for an external initramfs, so you need to embed a pre-built cpio image (using the CONFIG_INITRAMFS_SOURCE option).

Option2: create a standalone (non-modular) grub2

We now need to sign the bootloader. While this is a simple operation, it will not work as-is with the default Debian installation: Grub, when it detects that SecureBoot is enabled, will refuse to load modules from the disk.

There is no support in Grub to support a signature + verification module, so a workaround is to create a Grub executable with all required modules embedded.

Create a file modules_grub, with the following content:

minicmd
help
gfxterm_background
video_colors
bitmap_scale
search
search_label
search_fs_file
search_fs_uuid
password_pbkdf2
pbkdf2
gcry_sha512
all_video
video_cirrus
video_bochs
loadenv
disk
test
fat
lzopio
xzio
gzio
png
bitmap
gfxterm
font
bufio
efi_uga
efi_gop
video
video_fb
ext2
fshelp
part_gpt
normal
boot
extcmd
crypto
terminal
gettext
echo
linux
linuxefi

The content of this file was created by try-and-fail, so you may need to adapt it to your configuration.

Install Grub, embedding these modules to the resulting executable:

# grub_modules="$(cat modules_grub)"
# grub-install --uefi-secure-boot --modules="$grub_modules"

Sign the Grub executable:

$ sudo sbsign --key boot0.key --cert boot0.crt /boot/efi/EFI/debian/grubx64.efi
$ sudo mv /boot/efi/EFI/debian/grubx64.efi.signed /boot/efi/EFI/debian/grubx64.efi

Note: you will need to sign the Grub executable every time grub is reinstalled (but not when only the configuration is changed).

Optional: sign a UEFI shell, put it on a USB drive

To make things easier to maintain, I also signed a local version of the EDK2 UEFI Shell. This shell will not be present on the boot partition, but it can be useful to keep a USB drive with a bootable shell (for recovery). You can also add a local Grub installation on this key, for example.

Remember that SecureBoot will verify signatures of all executables (not only the first). This means that if you use the shell to run other programs, these programs also need to be signed.

Configure the Firmware

Reboot, and enter your Firmware configuration. These steps vary from one Firmware to another, so here are listed the important steps:

disable the CSM (Compatibility Support Module)
disable legacy boot support, enable UEFI only
go into Setup Mode and/or clear all certificates

SecureBoot is not enabled now if you need to reboot to setup the keys.

Setup certificates

Some Firmwares have menus to add/remove keys (it’s not the case for me). Another solution is to use efitools to configure the keys from the UEFI shell.

Add the executables to the USB drive. You will need at least KeyTool.efi, the other executables are not used here.

On my laptop, Setup Mode is only available the first boot after setting the option (which is a good thing). Run KeyTool.efi, and then:

add the PK
add the KEK
add the DB
add the empty dbx file

Profit!

On the next reboot, enable SecureBoot in the Firmware, and then your Firmware should only load signed images, with a trusted certificate.

If something goes wrong, reboot and disable SecureBoot.

And now ?

This is only the beginning of the trust chain! To achieve full boot integrity, all elements from the boot sequence must support integrity checks.

For example, if the bootloader does not check the integrity of the kernel image, or the initramfs, then this image could easily be compromised. After the boot, if the kernel does not check the modules it will load, then it could also be compromised.

The following points are not mutually exclusive, but more parts of a complete solution:

the TPM: The Trusted Platform Module (TPM) is one possible solution: by sealing a key to the values of some measurements, this can tie, for example, the extraction of the disk encryption key to the fact that the expected values were found. This, however, requires a modified bootloader and some additions to the initramfs. I may post something about that in the future.
Kernel signed modules: since Linux kernel version 3.7, support has been added for signed kernel modules (CONFIG_MODULE_SIG and CONFIG_MODULE_SIG_FORCE). This allows further hardening of the system by disallowing unsigned kernel modules, or kernel modules signed with the wrong key, to be loaded. See Signed kernel module support for more details.

In UEFI, the correct term is Firmware. Think of BIOS and Firmware as the same thing, I’ll just use the word Firmware for consistency. ↩
Remember, the problem is not your OEM or Microsoft, but the fact that you don’t own all the keys and so cannot choose what can boot or not. ↩

Prelude Correlator in Debian

The Prelude Correlator is now packaged in Debian.

From the description of the package:

Prelude is a general-purpose hybrid intrusion detection system.
.
This package provides the Prelude Correlator, which is a powerful
correlation engine using Lua to write correlation rules.
.
The features currently include:
 * Rapid identification of important security events, enabling the analyst to
   assign task priorities
 * Alert correlation originally from heterogeneous sensors deployed on the
   whole infrastructure
 * Real-time analysis of events received by the Prelude Manager

You can contribute ! If you use the correlation engine, please share your correlation rules.

gcc security features (part 2)

(See part 1)

Remember: you must compile with -02 if you want the checks to be effective

DEB_BUILD_HARDENING_FORTIFY (gcc/g++ -D_FORTIFY_SOURCE=2)

The idea behind FORTIFY_SOURCE is relatively simple: there are cases where the compiler can know the size of a buffer (if it’s a fixed sized buffer on the stack, as in the example, or if the buffer just came from a malloc() function call). With a known buffer size, functions that operate on the buffer can make sure the buffer will not overflow.

Example:

void foo(char *string)
{
    char buf[20];
    strcpy(buf, string);
}

Execution will fail:

[home ~/harden] ./bad $(perl -e 'print "A"x100')
zsh: segmentation fault  ./bad $(perl -e 'print "A"x100')

When compiling with -D_FORTIFY_SOURCE=2, gcc will add some checks to detect the overflow and terminate the program:

[home ~/harden] DEB_BUILD_HARDENING=1 make
[home ~/harden] ./bad $(perl -e 'print "A"x100')

*** buffer overflow detected ***: ./bad terminated
======= Backtrace: =========
/lib/libc.so.6(__fortify_fail+0x37)[0x2ba8d18fb787]
/lib/libc.so.6[0x2ba8d18f9e70]
./bad(main+0x26)[0x555555554856]
/lib/libc.so.6(__libc_start_main+0xf4)[0x2ba8d18411c4]
./bad[0x555555554789]
======= Memory map:  ========
2ba8d1607000-2ba8d1622000 r-xp 00000000 03:01 468316                     /lib/ld-2.7.so
2ba8d1622000-2ba8d1625000 rw-p 2ba8d1622000 00:00 0
2ba8d1821000-2ba8d1823000 rw-p 0001a000 …

gcc security features (part 1)
Date Wed 02 April 2008 Tags Security Compiler Debian

Since recent versions (>= 4.0, maybe before), gcc (and ld) has some nice security features. Debian has created a wrapper for the toolchain, to make the use of these features easy.

To install the wrapper, run:
```
apt-get install hardening-wrapper
```
To enable the hardening features, you have to export the environment variable:
```
export DEB_BUILD_HARDENING=1
```
The features include additional checks for printf-like functions, stack protector, using address-space layout randomization (ASLR), marking ELF-sections as read-only after loading when possible, etc.

Please note that you must compile with *-02* if you want the checks to be effective

DEB_BUILD_HARDENING_FORMAT (gcc/g++ -Wformat -Wformat-security)

Ask gcc to make additional checks on format strings, to prevent attacks.

The following code, for ex:
```
printf(buf);
```
will result in a warning:
```
[home ~/harden] DEB_BUILD_HARDENING=1 make
gcc     bad.c   -o bad
bad.c: In function ‘main’:
bad.c:10: warning: format not a string literal and no format arguments
```
Why is this code vulnerable ? Because the buffer (buf) could contain format characters like %s, and the printf function will interpret these characters to pop arguments from the stack, and can result in the execution of arbitrary code.

Solution:
- Replace previous code by
```
printf("%s",buf);
```
- Remember this …
read more
